Description

The Pico Technology Milliohm & Motor Tester (MT03A) is the ultimate low-resistance testing tool designed to quickly and accurately test the earth-bonding integrity and motor winding resistance on electric motors of various kinds. This tool can also measure the resistance of switches, relays, connectors, bus bars, general wiring and to isolate communication circuit issues.

Features & Benefits

• Exceptional Accuracy
  • Measures resistance to 10u? vs. typical multimeters of 100m?
  • Provides temperature compensation to remove thermal deviation
  • Uses Kelvin clips to minimize contact resistance effects
  • Supplies a 200 mA test current to energize circuit for optimal detection
• Easy, Fast and Clear User Interface
  • Intuitive software simplifies configuration, operation and test results
  • Tests all three windings of three-phase motors in less than 1 minute
  • Logs resistance values as a time-based waveform and assigns a numeric value
• Multiple Applications
  • With its earth-bond testing in compliance with UB ECE R100 regulations and a minimum test current of 200 mA, the MT03A has widespread applications: fuel pumps, air-conditioning motors, regeneration pumps, blower motors, camshaft controls, EGR valves, turbo actuators and more
  • Perfect for checking grounds to ECUs, earth straps, starter motor cables, safety grounds, weld contact quality and earth bond testing
  • Designed for technicians and engineers in a wide range of industries: automotive, off-highway, heavy-duty, industrial, marine, rail, mining, heavy equipment, access machines and renewable energy
• User-Friendly and Portable
  • The device is connected and powered through USB 2.0 to a Windows-based tablet or laptop with dedicated software providing a clear user interface for simplicity, speed and complete control over the tester

Includes

• MT03A Milliohm & Tester Device
• PQ319 Kelvin Test Leads
• TA527 Temperature Probe
• MI121 USB 2.0 Cable
• MI168 Engine Bay Test Hook
• DO361 Start Up Guide
• DO363 Manual

Warranty

Warranted against defects in material and workmanship only.
