Description

The John Bean 15k 4-Post Alignment Lift is equipped to provide professional grade alignment lifting for a variety of vehicle sizes. With open-front columns and ultra-wide 26” runways, this lift is ready to make light work of heavy-duty, dual-rear-wheel trucks and equally suited to accommodate standard, four-wheel alignments on passenger vehicles.

Features

• Wider Rear Column Clearance
  • Extended rear column drive-on clearance
  • 120” drive-on clearance / 125” body clearance
  • Allows dual-wheel trucks to drive on without interference
  • Imaging alignment compatible – easily accommodate split-roll during alignment – using AC200 or AC400 clamps
• Pro-style Runways
  • Best-in-class, ultra-wide, 26” runways for wide track width vehicles
  • Ultra-low-profile allows “easy-on” approach angle for low-profile vehicles, lowered height just 8”
  • Pre-assembled with pulleys, pins, cables, cylinder, pull bar for quicker installation and factory-verified fit/function
• Enhanced Rear Slip Plates
  • Extra-long 100” rear slip plates for improved 4-wheel alignment capability for long and short wheelbase vehicles
  • Flush mount, full-floating slip plate with Delrin® polymer ball-transfer unit, engineered for low-maintenance performance
  • Rolled outside edges provide additional strength and flatness for heavy vehicles
• Open Front Cross Beam
  • Easy access to service areas for hassle-free adjustments and repairs
  • Micro-adjustment leveling set screws on front and rear cross beam
  • Adjustable, folding 4” front wheel stops have clearance for long, low-profile vehicles
• Textured Ramps
  • Ultra-wide ramps with anti-slip textured surface
  • Increased traction for improved vehicle loading, especially in wet or slick conditions
  • Low approach angle for easy transition from floor to alignment deck
• Innovative Cable Brake Lock
  • Cartridge-based locking and cable brake system for ease of maintenance

Includes

• 7.5 Capacity Adjustable Roller Jacks, Set of 2, EELR545A
• Premium Front Radius Turnplates, EEAK0289J06A
• EAK0277J28A Paddle Kit for premium Turnplates

Warranty

• Five Years - Structural Components
• 2 Years -  Air Supplied Items, Hydraulics, Electric Hydraulic Power Packs and Consoles, and other functional parts
• 1 Year - Labor and Protective Coating (against adhesion failure)
• 90 Days - Consumable Lift and Accessory items
